280kv Industrial X Ray Radiography NDT For Ship Building Inspection RD-2805TH

  • 1
  • 2
  • 3

Brand Name : HUIWEI

Model Number : RD-2805TH

Certification : ISO 9001, CE

Place of Origin : ZHEJIANG, CHINA

MOQ : 1 set

Price : 12000usd/set

Payment Terms : L/C,T/T,Western Union,MoneyGram

Supply Ability : 500sets within one month

Delivery Time : 15working days

Packaging Details : Standard export plywood package

Product name : Industrial x ray testing xxg3005,x-ray welding machine ndt,X-ray Inspection Systems,NDT industrial film processing machine,industrial NDT equipment NDT x ray testing machine

Warranty : 12 Months

Usage : spaceflight industry, welding engineering industry, shipbuilding industry inspection

Power supply : AC220V±10%

Application : Industrial field

Function : steel defect,NDT inspection welding

Color : Stainless Steel,Silver gray,blue and white

Max.penetration : 40mm(A3 STEEL)

Film type : Any kinds of industrial film

Voltage : 150-280kv

Exposure time : 15 minutes

Name : NDT industrial x-ray machine

Tube current : 5mA

Controller Weight : 12kg

Focus Spot : 1.0*2.4

Generator Weight : 27kg

Contact Now

Portable Industrial Xray Machine for Advanced Non-Destructive Testing and Inspection in Industrial Applications

The RD-2805 represents an advanced radiographic inspection system featuring automated intelligent operation management. Its primary technological advantage lies in exceptional electromagnetic interference resistance. The equipment operates with an optimized 4:1 duty cycle ratio, supporting extended continuous operation periods up to 15 minutes per exposure session. This product line offers both directional (40±5° beam angle) and panoramic (360° coverage) radiation configurations, demonstrating 45mm penetration capability on A3-grade steel specimen.

Portable Industrial Solution:
Engineered for demanding field applications and elevated work environments, this compact system (26kg generator unit) combines superior penetration performance with operational reliability14. Its ruggedized design ensures consistent performance in challenging industrial settings1.

Key Advantages:
• Certified equipment for critical infrastructure projects including China's inaugural 1GW power generation facility
• Innovative high-voltage technology enabling rapid exposure cycles - validated through 10,000 radiographic tests within one month1
• Compact form factor with vibration-resistant construction for mobile applications.
• Ideal for confined space operations in energy infrastructure and marine construction sectors
• Enhanced workflow efficiency through continuous operation capability (50% productivity improvement versus conventional systems)
• Reduced maintenance requirements due to robust component design

Main uses:

280kv Industrial X Ray Radiography NDT For Ship Building Inspection RD-2805TH

RD-2805TH the technical parameters

Project

RD-2805TH

input

Input power

Single-phase 50Hz AC 220± 10% V

Power supply capacity

No less than 2.0 KVA

output

X - ray tube voltage

150-280 KVp

X ray tube current

5mA

mA Stability degree

± 1%

Ray tube

Focal size

1.0× 2.4

X-ray irradiation range

360°*25°

Ray generator

working pressure

Cooling mode

Insulation way

0.45MPa ~ 0.5Mpa

Anode ground connection radiator Strong wind cold

Gas insulation SF6

Size

weight (kg)

Φ280mm´280mm´620mm

27

Maximum penetration

Thickness steel A3(mm)

40 mm Fe(5 min)

condition

focal distance 600mm ,Agfa film,Double lead foil,Liquid temperature 22,Film density ≥1.5

sensitivity

superior 2%

controller

Size

weight

Circuit

325×270×180

< 9(kg)

Automatic control and protection

Environment

working temperature relative humidity

Altitude

-30°~ +40°

Not more than 85%

Not higher 1500m

methods

fully automatic 2.5:1 Work and rest,Longest continuous exposure time 15mins

FAQ

1. Is your Company the Manufacturer or a Trading Company?

We are a manufacturer of NDT x ray equipment in China with experience engineer working over 30 years.

2. What's the MOQ ?
(1). Normally, MOQ is 1 piece. The quantity is depending on the clients’ needs.
(2)According to customer order, the quantity still can be negotiated and we will product immeditaly if we dont have stock.

3. What is your principle for the samples ?
No free samples. But we provide 1piece as a sample order for all items.
