5mA Industrial Field Portable X Ray Flaw Detector With Ceramic X Ray Tube

Name: 5mA Industrial Field Portable X Ray Flaw Detector With Ceramic X Ray Tube
Brand: HUIWEI
Price: 19000 USD

Quality 5mA Industrial Field Portable X Ray Flaw Detector With Ceramic X Ray Tube wholesale

Brand Name : HUIWEI

Model Number : RD-3005

Certification : ISO 9001, CE

Place of Origin : ZHEJIANG, CHINA

MOQ : 1 set

Price : 19000usd/set

Payment Terms : L/C,T/T,Western Union,MoneyGram

Supply Ability : 500sets within one month

Delivery Time : 15working days

Packaging Details : Standard export plywood package

Power supply : AC220V±10%

Generator Weight : 28kg

Function : steel defect,NDT inspection welding

Color : Stainless Steel,Silver gray,blue and white

Max.penetration : 50mm(A3 STEEL)

Film type : Any kinds of industrial film

Exposure time : 5 minutes

Warranty : 12 Months

Application : Industrial field

Name : NDT industrial x-ray machine

Tube current : 5mA

Controller Weight : 9kg

Voltage : 170-300kv

Focus Spot : 0.9*0.9

Contact Now

X-ray Ndt Manufacturer Ndt Testing Portable X-ray Flaw Detector with Ceramic X Ray Tube

X Ray NDT Equipment/ NDT Radiographic Testing/NDT Flaw Inspection

NDT radiographic testing is a nondestructive testing (NDT)that uses x ray to examine the internal structure of some materials. The term NDT stands for non-destructive testing. This type of testing is often used in the manufacturing and aerospace industries. NDT X-ray testing can be used to detect a variety of different flaws, including cracks, porosity, and inclusions.

Main uses:

The company's products have been widely used in oil and gas pipelines, long-distance pipelines, boiler pressure vessels, chemical industry, aerospace, military and other fields. It has established long-term strategic cooperative relations with large enterprises such as PetroChina, Sinopec, chemical equipment manufacturing, and aerospace special equipment.

Huiwei adheres to the business philosophy of people-oriented, pragmatic innovation, honest management, and pursuit of excellence, and takes "promoting the cause of non-destructive testing" as the development orientation, and strives to realize "being the most influential industrial X-ray machine in China". We believe that with excellent technology, high-quality products, comprehensive services and unlimited innovation capabilities, we will surely assist customers to realize their dreams.

5mA Industrial Field Portable X Ray Flaw Detector With Ceramic X Ray Tube

RD-3005the technical parameters

	Project	RD-3005
input	Input power	Single-phase AC150-250V 50/60Hz
input	Power supply capacity	No less than 3.0 KVA
output	X - ray tube voltage	150~ 300 KVp
	X ray tube current	5mA
	mA Stability degree	± 1%
Ray tube	Focal size	2.5× 2.5
Ray tube	X-ray irradiation range	40±5°
Ray generator	working pressure Cooling mode Insulation way	0.35MPa ~ 0.5Mpa Anode ground connection radiator Strong wind cold Gas insulation SF6
	Size weight (kg)	φ320×640
	Size weight (kg)	34
Maximum penetration	Thickness steel A3(mm)	50 mmFe(5 min)
Maximum penetration	condition	focal distance 600mm ,Agfa film,Double lead foil,Liquid temperature 22,Film density ≥1.5
	sensitivity	superior 2%
controller	Size weight Circuit	325×270×180 < 9(kg) Automatic control and protection
Environment	working temperature relative humidity Altitude	-30°~ +40° Not more than 85% Not higher 1500m
methods	fully automatic 4:1 Work and rest,Longest continuous exposure time 15mins

5mA Industrial Field Portable X Ray Flaw Detector With Ceramic X Ray Tube
